Gigabyte G493-ZB3 4U GPU Server

SKU: AH-GPU412-GA04

Featured Product Image

Key Features:

  • Supports up to 8 dual-slot GPU cards
  • AMD EPYC™ 9004 series processors
  • 12-Channel RDIMM DDR5, 48x DIMMs
  • 2x 1Gb/s BASE-T LAN ports (Intel® I350-AM2)
  • 12x 2.5" Gen5 NVMe/SATA hot-swappable bays
  • 3+1 3000W 80 PLUS Titanium redundant power supply
Request a Quote

$0.00

Share this product:

Description

HPC 4U DP 8x Gen5 GPU Server | Application: AI, AI Training, AI Inference & HPC

Processor

CPU Quantity 2
CPU Socket Socket SP5 (LGA 6096)
CPU Manufacturer AMD
CPU Supported EPYC™ 9005/9004 series processors
Cores Up to 128-cores, 256 threads
GPU Support Up to 8 GPU

Memory

Memory Capacity Up to 128GB RDIMM/LRDIMM Supported
Up to 256GB 3DS RDIMM/LRDIMM Supported
Memory Type DDR5 memory supported only
Memory Speed Up to 4800 MHz (1DPC), 3600 MHz (2DPC)
Memory Slots 48

On-board

Chipset System on Chip
System Management
 Aspeed® AST2500 management controller
Gigabyte Management Console (AMI MegaRAC SP-X) web interface
Graphics Aspeed AST2500

Expansion Slots

PCI Express

4x PCIe x16 (Gen5 x16) FHFL slots, from PEX89144_0, for GPUs
4x PCIe x16 (Gen5 x16) FHFL slots, from PEX89144_1, for GPUs


4x PCIe x16 (Gen5 x16) low-profile slots, from PEX89144_0
4x PCIe x16 (Gen5 x16) low-profile slots, from PEX89144_1


1x PCIe x16 (Gen5 x16) low-profile slot on front side, from CPU_0
1x PCIe x16 (Gen5 x16) low-profile slot on front side, from CPU_1
M.2 1x M.2 slot:
M-key
PCIe Gen3 x4, from CPU_0
Supports 2280/22110 cards

1x M.2 slot:
M-key
PCIe Gen3 x4, from CPU_1
Supports 2280/22110 cards

Drive Bays

Storage
 Front side:
12x 2.5" Gen5 NVMe/SATA/SAS hot-swappable bays
(6x NVMe from CPU_0, 6 x NVMe from CPU_1)
SAS card is required for SAS devices support

Input/Output


Internal I/O
 2x M.2 slots
1x TPM header
Front I/O
 2x USB 3.2 Gen1
1x VGA
2x RJ45
1x MLAN
1x Power button with LED
1x ID button with LED
1x Reset button
1x NMI button
1x System status LED
1x HDD access LED
Rear I/O
 N/A
Backplane I/O Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS 12Gb/s
LAN Front side:
2x 1Gb/s BASE-T LAN ports (1x Intel® I350-AM2)
NCSI function supported

1x 10/100/1000 management LAN
TPM 1 TPM header with SPI interface
Optional TPM2.0 kit: CTM010

Cooling

System Fans 6x 60x60x38mm (23,000rpm)

Power

Power Supply 3+1 3000W (240V) redundant power supplies
Certification 80 Plus Titanium

Dimensions

Form Factor Rackmount
Rack Height 4U
Height 6.92" (176mm)
Width 17.63" (448mm)
Depth 34.64" (880mm)
Weight Net Weight: 66.13 lbs (30 kg)
Gross Weight: 79.36 lbs (36 kg)
